DPA 4063 CORE Omni Mic, Loud SPL & DC, Beige, MicroDot
Please contact us on +45 3120 7021 or info@nordicproaudio.com
The 4063 Miniature Omnidirectional Microphone, Loud SPL and Low voltage is designed for use with transmitters giving only 3V bias voltage. Some transmitters provides only 3V instead of the more common 5V. In this case, the 4063 is the right choice for such transmitters. With the correct power source, the microphone will be able to handle sound pressure levels up to 138 dB before clipping occurs.
- For LOUD SPL
- Exceptional audio quality
- Uniform, consistent sound between DPA mics
- Extremely rugged and reliable
- Diminutive size made for flexible and easy concealment
- Large selection of clips, windscreens, grids and other accessories
- Modular adapter system fits most professional wireless systems
DPA 4063 Frequency Response:
Typical response of a 4063
DPA 4063 Polar Pattern:
Typical directional characteristics of a 4063
- 1x DPA 4063 Omni CORE mic
- 1x Soft boost grid
- 1x High boost grid
Directional Pattern: | Omnidirectional |
---|---|
Principle of operation: | Pressure gradient |
Cartridge type: | Pre-polarized condenser |
Frequency response: | 20 Hz - 20 kHz |
Dynamic range: | Typ. 109 dB |
Color: | Beige |
Effective frequency range ±2 dB: | Soft boost grid: 20 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz. High boost grid: 20 Hz - 20 kHz, 10 dB boost at 12 kHz |
Sensitivity, nominal, ±3 dB at 1 kHz: | 6 mV/Pa; -44 dB re. 1 V/Pa |
Equivalent noise level, A-weighted: | Typ. 26 dB(A) re. 20 µPa (max. 28 dB(A)) |
Equivalent noise level, ITU-R BS.468-4: | Typ. 38 dB (max. 40 dB) |
Distortion, THD < 1%: | 132 dB SPL RMS, 135 dB SPL peak |
Max. SPL, THD 10%: | 138 dB SPL peak |
Rated output impedance: | 30 - 40 Ω |
Cable drive capability: | Up to 300 m (984 ft) with DAD6001-BC XLR adapter |
Power supply (for full performance): | For wireless systems Min. 3 V - max. 10 V |
Current consumption: | Typ. 1.5 mA (microphone). 3.5 mA with DAD6001-BC XLR Adapter |
Polarity: | Positively increasing sound pressure produces positive going voltage on MicroDot pin |
Weight: | 7.5 g (0.26 oz) incl. Cable and MicroDot connector |
Microphone diameter: | 5.4 mm (0.21 in) |
Microphone length: | 12.7 mm (0.5 in) |
Cable length: | 1.8 m (5.9 ft) |
Temperature range: | -40°C to 45°C (-40°F to 113°F) |
Relative humidity (RH): | Up to 90% |
